Releasable Metal Ties

This type of stainless steel tie, available in grade 316 & 304 is releasable and reusable.

These ties can be supplied with or without coating in a wide combination of lengths and widths, as well as colors for the coated type.

Fasten-unfasten-refasten means greater flexibility with the releasable tie.

Normal operating range for the coated version is -60°C to +165°C. Coated ties have better weathering properties with excellent resistance to corrosion, radiation and abrasion.

  • Releasable and re-usable.
  • Corrosion resistant 316 grade stainless steel for high mechanical and chemical durability.
  • Fully coated version with non-toxic, Halogen free Polyester coating for a superior protection and cables and installer's hands and for an improved insulation between dissimilar materials.
  • Fast, easy and reliable installation - can be installed by hand and if necessary, the slots at the end of the tie allow the use of a hook type tool.
  • The additional ears can be bent back over the fastened tie to increase the tensile strength.
  • Applications: installation of cables and pipes in extreme conditions and hazardous areas, indoor and outdoor, such as: petrochemical and food processing industries, power, shipbuilding, offshore and other aggressive environments.
STAINLESS STELL CABLE TIES
TYPE : RELEASABLE - COATED & UNCOATED
Grade : 316 or 304
Part No. Length mm Width mm Max. Bundle Dia mm
RCT150/5 150 5 36
RCT230/5 230 5 60
RCT300/5 300 5 85
RCT330/5 330 5 95
RCT450/5 450 5 130
RCT610/5 610 5 180
RCT650/5 650 5 190
RCT762/5 762 5 230
RCT840/T 840 5 250
RCT914/5 914 5 275
RCT1000/5 1000 5 300
RCT1400/5 1400 5 430
RCT1600/5 1600 5 500
RCT150/5 150 10 40
RCT230/5 230 10 60
RCT300/5 300 10 85
RCT330/5 330 10 95
RCT450/5 450 10 130
RCT610/5 610 10 180
RCT650/5 650 10 190
RCT762/5 762 10 230
RCT840/T 840 10 250
RCT914/5 914 10 275
RCT1000/5 1000 10 300
RCT1400/5 1400 10 425
RCT1600/5 1600 10 500
  • Intermediate Lengths available on demand
  • Add Suffix A for 304 Grade : Suffix C for Coated version to Part Nos.
Part No. Coated Uncoated
Minimum Loop Tensile Strength : 7 mm width 136 Kgs. (1335N) 181 Kgs. (1779N)
Minimum Loop Tensile Strength : 12 mm width 224 Kgs. (2200N) 224 Kgs. (2200N)
